Industrial Mining Conveyor Light

LTC's heavy duty conveyor light – sturdy, energy efficient and customisable to your project requirements.

This is a tough, versatile and very effective conveyor light that has many other applications. It is dust, water, chemical, vibration and corrosion proof. It has been designed with clean and smooth surface housing minimises dust accumulation.

The LTC Industrial Mining Conveyor Light uses Lumiled LEDs, providing excellent lumen output with unique light distribution and delivers high quality lighting with energy efficiency and long-lasting stability. The sturdy design with corrosion resistant housing and low susceptibility to vibration provides long lifespan in a wide range of applciations.

The product has wide application across gantries, walkways, port facilities, coal preparation, tunnels and just about any other heavy duty application required.

The LTC Industrial Mining Conveyor Light can be customised to your project requirements – Microwave motion sensor, daylight sensor and other custom smart systems available.

Product details

  • IP66
  • Corrosion, vibration, and chemical resistant
  • Anodised and powder coated for extra life
  • Tough aluminium housing – chemical and corrosion resistant
  • Clean and smooth surface housing minimises dust accumulation.
  • No stroboscopic flickering
  • 3 year warranty (5-year extended warranty available)
  • Government energy rebates available

Product applications

  • Mining Conveyor Gantries and Walkways
  • Wharf and Port Facilities
  • Material Handling Machines
  • Coal Preparation Plants
  • Draglines
  • Transfer Towers
  • Access Stairways
  • Tunnels
  • Sewerage Treatment Plants
  • General Security Lighting
  • Heavy Industries
  • Pedestrian Pathways
  • Marine Applications
  • Street Lighting
  • Area Lighting

ISO9001Global MarkIP66RCM TickIK10 Rated


Illumination grade CREE LED light source.


LED Driver

High-end programmable Inventronics or Tridonic (emergency) series LED driver, with 20KV surge protection provides excellent performance and lifespan.



The LTC Industrial Mining Conveyor Light can be customised to your project requirements.

IMC 35W IMC 35W Emergency IMC 55W IMC 55W Emergency
Item code 112083 112084 112026 112027
Nominal Wattage 35W 39W Emergency 55W 59W Emergency
AC input 240V 50Hz/60Hz
Power Factor >0.9
LED Brand Lumileds 5050
Driver Brand Inventronics or Tridonic (emergency driver)
Max. Current @ 240V 0.16A 0.17A 0.24A 0.26A
Operating Temperature Range 50°C 40°C 50°C 40°C
Leakage Current 0.7mA @ 240V AC
Battery Type - TridonicNiCd Accus 4.5 Ah - TridonicNiCd Accus 4.5 Ah
Charge Time - 24 Hrs - 24 hrs
EM Discharge Time Type - 3 hrs - 3 hrs
Emergency Classification - C0 /D12.5 , C90/ D80 - C0 /D12.5 , C90/ D80
Surge Protection 20KV
Lumen Output (+/-5%) 4235Lm 4719Lm 6325Lm 6785Lm
Luminaire Efficacy (+/-5%) 121Lm/W

121Lm/W (Mains)
134Lm/W (Emergency)


115Lm/W (Mains)
134Lm/W (Emergency)

Luminaire Classification Class I
Light Distribution Type Type I (Type II, Type III, & Type IV Optional)
CRI 70 (80 Optional)
CCT 5000K (Amber, 2700K-6500K Optional)
IP Rating IP66
Impact Rating IK10
Mouting Options Pole mounted with spigot
Spigot Size 34mm (42mm Optional)
Accessories Safety lanyard (Optional)
Cable Gland M20, Nylon 66
Cable Ø Entry Range 7 - 13mm
Body Material Anodised and powder coated high grade Aluminium
Finish Grey
Optics/Lens Cover Polycarbonate
Projected Rated Life (LED) LM80/TM21 >60KHrs
Certifications Global Mark, RCM, ISO9001:2015

The tolerance range of test data above is ±6%,  but normally warm white is ±8%.


Detailed dimension drawings and polar diagrams are available from our team. Get in touch to discuss with our lighting experts.
Measurements and illustrations are approximate, do not scale.

IMC 35W IMC 35W Emergency IMC 55W IMC 55W Emergency
Dimensions (mm) 160 x 565 x 108 160 x 565 x 108 160 x 565 x 108 160 x 565 x 108
Weight Approx. 5kg Approx. 5kg Approx. 5kg Approx. 5kg
LTC Industrial Mining Conveyor Light dimensions
Industrial Mining Conveyor Light

Photometric distribution

Polar diagramAverage beam angle (50%): 147.7º
